Vmaxtanks XTR31-135 AGM Deep Cycle

12V 135Ah Extreme Series Battery

The Vmaxtanks XTR31-135 AGM 12V 135Ah deep-cycle battery (Group Size 31) is built for unmatched performance, durability, and versatility. As part of the Xtreme Series and weighing 74 lbs, this powerhouse delivers exceptional deep-cycle capabilities, fast charge times, and long-lasting power. It is designed to excel in all deep-cycle applications, including marine, cranking, solar systems, and RVs. However, it truly shines in golf carts and demanding industrial machinery such as lifts, floor scrubbers, and other heavy-duty equipment, where consistent, reliable power is critical.

Engineered with advanced technology, the XTR31-135 AGM battery is also an excellent choice for electric vehicles (EVs), providing the high performance and efficiency needed for daily use. With dual post terminals for versatile connections, this battery offers superior energy storage, resistance to vibrations, and the ability to withstand harsh conditions. Whether powering industrial machines, off-grid solar systems, or weekend RV adventures, the Vmaxtanks XTR31-135 AGM battery delivers years of dependable service with maximum performance and reliability.

1-Year Manufacturer's Replacement Warranty.

Connect in Series or Parallel

BCI GROUP: 31

Specifications:

Nominal Voltage: 12V
20Hr Capacity: 135Ah
Cold Cranking Amps (CCA): 730A
Marine Cranking Amps (MCA): 920A
Reserve Capacity (RC): 265 minutes
Energy: 1.8 kWh
Terminal Posts: 8mm (included)
Dimensions: 13" (width) x 6.8" (depth) x 8.4" (height); 8.7" total height including terminal posts
Weight: 74 lbs
Charging Current: 10A-35A
Charging Voltage: 14.4V-14.9V
Float Voltage: 13.5V-13.8V
25A @1.75/Cell - 265 Min
75A @ 1.75/Cell - 75 Min
Short Circuit Current: 2500A
Internal Resistance: 3.2 mOhms

Recommended Charging Options:

AC Chargers: Any Quality Brand AGM- Smart & Microprocessor controlled- charger with the recommended specs above can be used.
Vehicle Alternator: 14V-15V.
RV Converter: 14V-15V.
Solar Panel: 175W-450W.
Wind Turbine: 175W-450W.
Charge Controller: 15A-UP

Warning: Do not use a charger with a smaller amperage than the recommended Charging Current shown above. Small maintainers should ONLY be used to maintain a fully charged battery but NEVER as a charger

Operating Temperature Range:

Discharge: -4~140F
Charge: 32~120F
Storage: -4~140F

Temperature Compensation

Cycle use: -30mV/C
Standby use: -20mV/C

All VMAXTANKS AGM Batteries Feature:

Sealed Construction
The unique construction and sealing techniques of VMAX tanks guarantee leak-proof operation in any position with no adverse effect on capacity or service life. VMAX tanks are classified as non-spillable, non-hazardous, dry batteries, making them NOT restricted for Surface, maritime, or Air Transport.
Electrolyte Suspension system
VMAX tanks utilize an electrolyte suspension system consisting of AGM (Absorbed Glass Matt) of high porosity that totally absorbs and contains the electrolyte. No silica gels or other contaminants are used.
Maintenance Free Operation
During the float's service life, there is no need to check the electrolyte's specific gravity or add water to VMAXTANKS™.
Reliable, Rugged Construction
The extra strong ABS container reduces case bulging and plate warping, ensuring long life and high performance.
Low-Pressure Valve Regulated System
All VMAXTANKS™ are equipped with safety release valves, designed to operate between 0.98 and 196.1kpa and automatically reseal. Hence, there is never an excessive accumulation of gas within the battery.
Heavy Duty Military Grade Grids
Heavy-duty lead tin alloy grids provide an extra margin of performance and service life in either float or cyclic applications, even after repeated over-discharges.
Cyclic Service Life
VMAX is known to deliver one of the highest numbers of discharge/recharge cycles.
Float Service Life
VMAXTANKS™ has an expected life span of 8 to 10 years in float service applications.
Low Self Discharge
The new VMAX tanks' self-discharge rate at room temperature is approximately 1-2% of rated capacity per month (compared to 2-3% for most other AGM batteries and 15-20% for Lead-Acid batteries).
Operating Temperature
VMAXTANKS™ may be operated over a broad range of ambient temperatures.
Ultra Low Resistance
VMAXTANKS™ Ultra Low Resistance makes it up to 99% efficient (compared to 85-95% as in Lead Acid Batteries and 97% in most other GEL and AGM batteries).
Higher Power Density
A special assembly technology is used to enhance power density to a considerable level.
